Description
VHT HEPA Diffusers
The VHT HEPA diffusers are also available with a fully-perforated front plate for vertical air supply or exhaust. The diffuser is designed to be equipped with HEPA filter with foamed polyurethane (PUR) gasket. Vita VHT diffuser is available in three sizes with two different types of duct connection.
Sizes
- 600 x 300
- 600 x 600
- 1200 x 600
Applications
- Cleanrooms in hospitals and laboratories
- Suitable for supply and exhaust ventilation
- Can be installed flush with the ceiling or wall
Key features
- Radial, swirl or low turbulent flow pattern
- Air supply through adjustable nozzles or perforated front panel
- Lockable nozzles that allow easy cleaning without changing the nozzles setting
- E10, H13 and H14 class standard and high airflow HEPA filters available
- Antibacterial epoxy-polyester powder paint finishing to prevent microbial growth
- Easy filter change through the front panel
- Test probe for measuring the filter pressure loss
- Test probe for measuring particle concentration above the filter
- Pressure difference transmitter to inform the user when to change the filter (optional).
Download Entropic HVAC software to instantly get detailed information on products and incorporate them into your project.
